| Brand Name : | BAMA |
| Price : | $50.00/pieces 1-4 pieces |
| Supply Ability : | 10000 Piece/Pieces per Month |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:1.00 ABSOLUTE | (A) Outer Diameter, Top: 5.92 IN (150.37 MM) | HANDLE:YES | |
Beta Rating: B1 = 200 | (B) Outer Diameter, Bottom: 5.92 IN (150.37 MM) | Seal Material: BUNA-N | |
Collapse Pressure Rating: 150 PSID | (C) Inner Diameter, Top: 3.79 IN (96.27 MM) | Type of Adhesive: EPOXY | |
Maximum Temperature: 225 F | (D) Inner Diameter, Bottom:3.79 IN (96.27 MM) | Type of Endcap: SYNTHETIC | |
Direction of Flow: OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:50 PSID | (E) Length: 14.63 IN (96.27 MM) | Center Tube: NONE | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: SQ.IN. | |||
Plating: NONE | |||
Outer Jacket: NONE - NONE | |||
Configuration: DOUBLE OPEN END | |||
|
|
