Langfang Bangmao Filter Equipment Co., Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | BAMA |
| Supply Ability : | 10000 Piece/Pieces per Month |
| Price : | $50.00/pieces 1-9 pieces |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:10.00 ABSOLUTE | (A) OUTER DIAMETER, TOP:4.96 IN (125.98 MM) | Handle: NONE | |
BETA RATING:B10=200 | (B) OUTER DIAMETER, BOTTOM:4.96 IN (125.98 MM) | Seal Material:BUNA-N | |
COLLAPSE PRESSURE RATING:145 PSID | (C) INNER DIAMETER, TOP:3.62 IN (91.95 MM) | Type of Adhesive：EPOXY | |
MAXIMUM TEMPERATURE:275 F | (D) INNER DIAMETER,BOTTOM:0.41 IN (10.41 MM) | TYPE OF ENDCAP:PLATED STEEL | |
Direction of Flow: INSIDE->OUT RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:50 PSID | (E) LENGTH:18.90 IN (10.41 MM) (F) THREAD:NONE | CENTER TUBE:NONE | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA:1507 SQ.IN. | |||
PLATING: | |||
OUTER JACKET:ZINC PLATED | |||
CONFIGURATION:YES | |||
|
|
