Brand Name : | BAMA |
Supply Ability : | 10000 Piece/Pieces per Month |
Price : | $50.00/pieces 1-9 pieces |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:0.50 NOMINAL | (A) Outer Diameter, Top:7.63IN | Handle:NONE | |
Beta Rating:N/A | (B) Outer Diameter, Bottom:7.63IN | Seal Material:BUNA-N | |
Collapse Pressure Rating:75PSID | (C) Inner Diameter, Top:5.63IN | Type of Adhesive: EPOXY | |
Maximum Temperature:225F | (D) Inner Diameter, Bottom:5.63IN | Type of Endcap:PLATEDE STEEL | |
Direction of Flow: INTSIDE->IN | (E) Length:13.63IN | Center Tube:PLATED STEEL | |
Get the quote by contacting us | Type of Media:FIBERGLASS | ||
Filter Area:936SQ.IN. | |||
Plating:ELECTROTIN PLATED | |||
Outer Jacket:YES - METAL | |||
Configuration:DOUBLE OPEN END |
![]() |
