| Brand Name : | BAMA |
| Certification : | ISO9001 |
| MOQ : | 1pcs |
| Price : | $20.00/pieces 1-4 pieces |
| Supply Ability : | 10000 Piece/Pieces per Month |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 6.00 ABSOLUTE | (A) Outer Diameter, Top: 3.33 IN (84.58 MM) | HANDLE:NONE | |
Beta Rating: B10=200 | (B) Outer Diameter, Bottom:3.33 IN (84.58 MM) | Seal Material: NONE | |
Collapse Pressure Rating: 450 PSID | (C) INNER DIAMETER, TOP:1.86 IN (47.24 MM) | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:225 F | (D) Inner Diameter, Bottom:** | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:14.69 IN (0.00 MM) | Center Tube: PLATED STEEL | |
Get the size by contacting us | Type of Media: MICROGLASS | ||
Filter Area: SQ.IN. | |||
Plating: ZINC PLATED | |||
Outer Jacket: YES | |||
Configuration: SINGLE OPEN END | |||
|
|
