Langfang Bangmao Filter Equipment Co., Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | BAMA |
| Supply Ability : | 10000 Piece/Pieces per Month |
| Price : | $10.00 - $50.00/pieces |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:10.00 | (A) OUTER DIAMETER, TOP:2.22 IN (56.39 MM) | Handle:NONE | |
BETA RATING:200/9.9 | (B) OUTER DIAMETER, BOTTOM:2.22 IN (56.39 MM) | Seal Material:VITON | |
COLLAPSE PRESSURE RATING:435 PSID | (C) INNER DIAMETER, TOP:1.00 IN (25.40 MM) | TYPE OF ADHESIVE: | |
MAXIMUM TEMPERATURE:248 F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP: | |
Direction of Flow: OUTSIDE->IN | (E) LENGTH:8.27 IN (0.00 MM) | CENTER TUBE: | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA:280 SQ IN | |||
PLATING: | |||
OUTER JACKET: | |||
CONFIGURATION: | |||
|
|
