Langfang Bangmao Filter Equipment Co., Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | BAMA |
| Supply Ability : | 10000 Piece/Pieces per Month |
| Price : | $10.00 - $50.00/pieces |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:3.00 ABSOLUTE | (A) OUTER DIAMETER, TOP:3.13 IN (79.50 MM) | Handle:NONE | |
BETA RATING:B3 = 200 | (B) OUTER DIAMETER, BOTTOM:3.13 IN (79.50 MM) | Seal Material:VITON | |
COLLAPSE PRESSURE RATING:150 PSID | (C) INNER DIAMETER, TOP:1.72 IN (43.69 MM) | TYPE OF ADHESIVE:EPOXY | |
MAXIMUM TEMPERATURE:275 F | (D) INNER DIAMETER,BOTTOM:1.72 IN (43.69 MM) | TYPE OF ENDCAP:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) LENGTH:17.01 IN (43.69 MM) | CENTER TUBE:PLATED STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA:SQ.IN. | |||
PLATING:ZINC PLATED | |||
OUTER JACKET:NONE - NONE | |||
CONFIGURATION:DOUBLE OPEN END | |||
|
|
