Langfang Bangmao Filter Equipment Co., Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | BAMA |
| Supply Ability : | 10000 Piece/Pieces per Month |
| Price : | $10.00 - $50.00/pieces |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:3.00 ABSOLUTE | (A) OUTER DIAMETER, TOP:3.89 IN (98.81 MM) | Handle:NONE | |
BETA RATING:B3 = 200 | (B) OUTER DIAMETER, BOTTOM:3.89 IN (98.81 MM) | Seal Material:BUAN | |
COLLAPSE PRESSURE RATING: | (C) INNER DIAMETER, TOP:1.59 IN (40.39 MM) | TYPE OF ADHESIVE:EPOXY | |
MAXIMUM TEMPERATURE:248 F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) LENGTH:8.43 IN (0.00 MM) | CENTER TUBE: PLATED STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA:505 SQ.IN | |||
PLATING: | |||
OUTER JACKET:NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
|
|
