Langfang Bangmao Filter Equipment Co., Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | BAMA |
| Price : | $45.00/pieces 1-9 pieces |
| Supply Ability : | 10000 Piece/Pieces per Month |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:6.00ABSOLUTE | (A) Outer Diameter, Top:2.00 IN (50.80 MM) | Handle:NONE | |
Beta Rating: B6=200 | (B) Outer Diameter, Bottom: 2.00 IN (50.80 MM) | Seal Material: BUNA-N | |
Collapse Pressure Rating: 150PSID | (C) Inner Diameter, Top:1.00 IN (25.40 MM) | Type of Adhesive: EPOXY | |
Maximum Temperature:250F | (D) Inner Diameter, Bottom: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:50 PSID | (E) Length:8.25 IN (0.00 MM) (F) THREAD:NONE | Center Tube:PLATED STEEL | |
Get the quote by contacting us | Type of Media:MICROGLASS | ||
Filter Area: 210SQ.IN. | |||
Plating:ZINC PLATED | |||
Outer Jacket:NONE-NONE | |||
Configuration:SINGLE OPEN END | |||
|
|
