Langfang Bangmao Filter Equipment Co., Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | BAMA |
| Price : | $30.00/pieces 1-9 pieces |
| Supply Ability : | 10000 Piece/Pieces per Month |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 3-20ABSOLUTE | (A) Outer Diameter, Top: 3.17 IN | Handle: NONE | |
Beta Rating: B6=200 | (B) Outer Diameter, Bottom:3.17 IN | Seal Material: BUNA-N | |
Collapse Pressure Rating: 150 PSI | (C) INNER DIAMETER, TOP:1.93 IN | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:225 F | (D) Inner Diameter, Bottom: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:13.00 IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: N/A | |||
Plating: ZINC PLATED | |||
Outer Jacket: NONE - NONE | |||
Configuration: SINGLE OPEN END | |||
|
|
