| Brand Name : | BAMA |
| Supply Ability : | 10000 Piece/Pieces per Month |
| Price : | $10.00 - $50.00/pieces |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:6.00 | (A) OUTER DIAMETER, TOP:1.75 IN (44.45 MM) | HANDLE:NONE | |
BETA RATING:B6=200 | (B) OUTER DIAMETER, BOTTOM:1.75 IN (44.45 MM) | Seal Material:BUNA | |
COLLAPSE PRESSURE RATING:150 PSID | (C) INNER DIAMETER, TOP:0.95 IN (24.13 MM) | Type of Adhesive：EPOXY | |
MAXIMUM TEMPERATURE:250 F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:PLATED STEEL | |
DIRECTION OF FLOW:OUTSIDE->IN | (E) LENGTH:4.45 IN (0.00 MM) | CENTER TUBE:PLATED STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA:N/A | |||
PLATING:N/A | |||
OUTER JACKET:NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
|
|
