Langfang Bangmao Filter Equipment Co., Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | BAMA |
| Supply Ability : | 10000 Piece/Pieces per Month |
| Price : | $10.00 - $50.00/pieces |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:12.00 ABSOLUTE | (A) Outer Diameter, Top:1.80 IN (45.72 MM) | Handle:NONE | |
Beta Rating:B12 =1000 | (B) Outer Diameter, Bottom:1.80 IN (45.72 MM) | Seal Material:VITON | |
Collapse Pressure Rating:3000 PSID | (C) Inner Diameter, Top:1.00 IN (25.40 MM) | Type of Adhesive:EPOXY | |
Maximum Temperature:275 F | (D) Inner Diameter, Bottom: | Type of Endcap:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:50 PSID | (E) Length:4.50 IN (0.00 MM) (F) THREAD:NONE | CENTER TUBE:PLATED STEEL | |
Get the quote by contacting us | Type of Media:MICROGLASS | ||
Filter Area: 95 SQ.FT.v | |||
Plating:ZINC PLATED | |||
Outer Jacket:NONE - NONE | |||
Configuration:SINGLE OPEN END | |||
|
|
