Langfang Bangmao Filter Equipment Co., Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | BAMA |
| Supply Ability : | 10000 Piece/Pieces per Month |
| Price : | $10.00 - $50.00/pieces |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:6.00 ABSOLUTE | (A) Outer Diameter, Top:3.90 IN (99.06 MM) | Handle:NONE | |
Beta Rating:B6 = 1000 | (B) Outer Diameter, Bottom:3.90 IN (99.06 MM) | Seal Material:BUNA-N | |
Collapse Pressure Rating:150 PSID | (C) Inner Diameter, Top:1.60 IN (40.64 MM) | Type of Adhesive: EPOXY | |
Maximum Temperature:250 F | (D) Inner Diameter, Bottom:1.60 IN (40.64 MM) | Type of Endcap:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:50 PSID | (E) Length:9.10 IN (40.64 MM) (F) THREAD:NONE | CENTER TUBE:PLATED STEEL | |
Get the quote by contacting us | Type of Media:MICROGLASS | ||
Filter Area: SQ.IN. | |||
Plating:ZINC PLATED | |||
Outer Jacket:NONE - NONE | |||
Configuration:SINGLE OPEN END | |||
|
|
