Brand Name : | BAMA |
Supply Ability : | 10000 Piece/Pieces per Month |
Price : | $10.00 - $50.00/pieces |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:3.00 ABSOLUTE | (A) Outer Diameter, Top:1.86 IN (47.24 MM) | Handle:NONE | |
Beta Rating:B3 = 200 | (B) Outer Diameter, Bottom:1.86 IN (47.24 MM) | Seal Material:VITON | |
Collapse Pressure Rating:3000 PSID | (C) Inner Diameter, Top:0.88 IN (22.35 MM) | Type of Adhesive: EPOXY | |
Maximum Temperature:400 F | (D) Inner Diameter, Bottom: | Type of Endcap:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:50 PSID | (E) Length:6.02 IN (0.00 MM) (F) THREAD:NONE | Center Tube:PLATED STEEL | |
Get the quote by contacting us | Type of Media:MICROGLASS | ||
Filter Area: SQ.IN. | |||
Plating:ZINC PLATED | |||
Outer Jacket:NONE - NONE | |||
Configuration:SINGLE OPEN END |
![]() |
