Langfang Bangmao Filter Equipment Co., Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | BAMA |
| Price : | $50.00/pieces 1-9 pieces |
| Supply Ability : | 10000 Piece/Pieces per Month |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 3.00 ABSOLUTE | (A) Outer Diameter, Top:3.63IN | Handle: NONE | |
Beta Rating: B3=200 | (B) Outer Diameter, Bottom: 3.63IN | Seal Material: VITON | |
Collapse Pressure Rating: 450 PSI | (C) Inner Diameter, Top: 1.94N | Type of Adhesive: EPOXY | |
Maximum Temperature: 250 F | (D) Inner Diameter, Bottom: IN | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length: 13.00IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: SQ IN. | |||
Plating:ZINC PLATED | |||
Outer Jacket: NONE | |||
Configuration: SINGLE OPEN END | |||
|
|
