Langfang Bangmao Filter Equipment Co., Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | BAMA |
| Certification : | 0.5kg |
| MOQ : | 1pcs |
| Price : | $25.00/pieces |
| Supply Ability : | 10000 Piece/Pieces per Month |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 25.00 ABSOLUTE | (A) Outer Diameter, Top: 2.75 IN (69.85 MM) | Handle: NONE | |
Beta Rating: B25=200 | (B) Outer Diameter, Bottom: 2.75 IN (69.85 MM) | Seal Material: BUNA-N | |
Collapse Pressure Rating: 150 PSI | (C) INNER DIAMETER, TOP:1.38 IN (35.05 MM) | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:225 F | (D) Inner Diameter, Bottom: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length: 6.88 IN (175 MM) | Center Tube: PLATED STEEL | |
Get the size by contacting us | Type of Media: 304 SS WIRE | ||
Filter Area: SQ IN. | |||
Plating: ZINC PLATED | |||
Outer Jacket: NONE | |||
Configuration: SINGLE OPEN END | |||
|
|
