| Brand Name : | BAMA |
| Certification : | ISO9001 |
| MOQ : | 1pcs |
| Price : | $60.00/pieces 1-4 pieces |
| Supply Ability : | 10000 Piece/Pieces per Month |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 6ABSOLUTE | (A) Outer Diameter, Top: 6.00 IN (152.40 MM) | HANDLE:NONE | |
Beta Rating: B6=200 | (B) Outer Diameter, Bottom:6.00 IN (152.40 MM) | Seal Material: BUNA-N | |
Collapse Pressure Rating: 150 PSI | (C) INNER DIAMETER, TOP:3.28 IN (83.31 MM) | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:225 F | (D) Inner Diameter, Bottom:3.28 IN (83.31 MM) | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:16.90 IN | Center Tube: PLATED STEEL | |
Get the size by contacting us | Type of Media: MICROGLASS | ||
Filter Area: 2270 SQ.IN. | |||
Plating: ZINC PLATED | |||
Outer Jacket: YES | |||
Configuration: SINGLE OPEN END | |||
|
|
