Brand Name : | BAMA |
Supply Ability : | 10000 Piece/Pieces per Month |
Price : | $50.00/pieces 1-9 pieces |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:25.00ABSOLUTE | (A) Outer Diameter, Top:3.07IN | Handle:NONE | |
Beta Rating: | (B) Outer Diameter, Bottom:3.07IN | Seal Material: VITON | |
Collapse Pressure Rating:305PSID | (C) Inner Diameter, Top:1.60IN | Type of Adhesive: | |
Maximum Temperature:248F | (D) Inner Diameter, Bottom: | Type of Endcap:PLATEDE STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:9.25IN | Center Tube:STEEL | |
Get the quote by contacting us | Type of Media:MICROGLASS | ||
Filter Area:551SQ.IN. | |||
Plating: | |||
Outer Jacket:NONE-NONE | |||
Configuration:SINGLE OPEN END |
![]() |
