Brand Name : | BAMA |
Supply Ability : | 10000 Piece/Pieces per Month |
Price : | $10.00 - $50.00/pieces |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:3.00ABSOLUTE | (A) Outer Diameter, Top:2.00IN | Handle:NONE | |
Beta Rating:B3=200 | (B) Outer Diameter, Bottom:2.00IN | Seal Material: VITON | |
Collapse Pressure Rating:3000PSID | (C) Inner Diameter, Top:1.00IN | Type of Adhesive: EPOXY | |
Maximum Temperature:250F | (D) Inner Diameter, Bottom: | Type of Endcap:PLATEDE STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:4.50IN | Center Tube:PLATED STEEL | |
Get the quote by contacting us | Type of Media:MICROGLASS | ||
Filter Area:165SQ.IN. | |||
Plating:ZINC PLATED | |||
Outer Jacket:NONE-NONE | |||
Configuration:SINGLE OPEN END |
![]() |
