Brand Name : | BAMA |
Supply Ability : | 10000 Piece/Pieces per Month |
Price : | $50.00/pieces 1-9 pieces |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:10.00 NOMINAL | (A) OUTER DIAMETER, TOP:5.08IN | Handle: NONE | |
Beta Rating:B10=200 | (B) Outer Diameter, Bottom: 5.08IN | Seal Material:BUNA | |
Collapse Pressure Rating: 75 PSID | (C) INNER DIAMETER, TOP: | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:225 F | (D) Inner Diameter, Bottom: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:8.98IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: SQ.IN. | |||
PLATING:ZINC PLATED | |||
Outer Jacket:NONE | |||
CONFIGURATION: |
![]() |
