| Brand Name : | BAMA |
| Supply Ability : | 10000 Piece/Pieces per Month |
| Price : | $50.00/pieces 1-9 pieces |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:10.00 NOMINAL | (A) OUTER DIAMETER, TOP:2.67 IN (67.82 MM) | HANDLE:NONE | |
BETA RATING:N/A | (B) OUTER DIAMETER, BOTTOM:2.67 IN (67.82 MM) | Seal Material:BUNA-N | |
COLLAPSE PRESSURE RATING:44 PSID | (C) INNER DIAMETER, TOP:1.20 IN (30.48 MM) | Type of Adhesive：EPOXY | |
MAXIMUM TEMPERATURE:248F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:PLATED STEEL | |
DIRECTION OF FLOW:OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:20 PSID | (E) LENGTH:5.40 IN (0.00 MM) (F) THREAD:NONE | CENTER TUBE:STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:PAPER | ||
FILTER AREA:254 SQ.IN. | |||
PLATING:N/A | |||
OUTER JACKET:NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
|
|
