Langfang Bangmao Filter Equipment Co., Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | BAMA |
| Supply Ability : | 10000 Piece/Pieces per Month |
| Price : | $50.00/pieces 1-9 pieces |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:3.00 ABSOLUTE | (A) OUTER DIAMETER, TOP:5.94 IN (150.88 MM) | HANDLE:NONE | |
BETA RATING:B3=200 | (B) OUTER DIAMETER, BOTTOM:5.94 IN (150.88 MM) | Seal Material:BUNA-N | |
COLLAPSE PRESSURE RATING:225 PSID | (C) INNER DIAMETER, TOP:3.55 IN (90.17 MM) | Type of Adhesive：EPOXY | |
MAXIMUM TEMPERATURE:225 F | (D) INNER DIAMETER,BOTTOM:3.55 IN (90.17 MM) | TYPE OF ENDCAP:PLATED STEEL | |
DIRECTION OF FLOW:OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:25 PSID | (E) LENGTH:15.74 IN (90.17 MM) (F) THREAD:N/A | CENTER TUBE:STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA:N/A | |||
PLATING:N/A | |||
OUTER JACKET:NONE | |||
CONFIGURATION:DOUBLE OPEN END | |||
|
|
