Langfang Bangmao Filter Equipment Co., Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | BAMA |
| Supply Ability : | 10000 Piece/Pieces per Month |
| Price : | $50.00/pieces 1-9 pieces |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:3.00 ABSOLUTE | (A) OUTER DIAMETER, TOP:2.75 IN (69.85 MM) | HANDLE:NONE | |
BETA RATING:B3=200 | (B) OUTER DIAMETER, BOTTOM: | Seal Material:BUNA-N | |
COLLAPSE PRESSURE RATING:3000 PSID | (C) INNER DIAMETER, TOP:1.37 IN (34.80 MM) | Type of Adhesive：N/A | |
MAXIMUM TEMPERATURE:225 F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:CORROSION REISITANT STEEL | |
DIRECTION OF FLOW:IN -> OUT RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:50 PSID | (E) LENGTH:13.75 IN (0.00 MM) (F) THREAD:NONE | CENTER TUBE:CORROSION REISITANT STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA:SQ.IN. | |||
PLATING:ZINC PLATED | |||
OUTER JACKET:NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
|
|
